| Gross mass (kg) |
Gross mass (kg) |
12490 |
| Curb mass (kg) |
Curb mass (kg) |
4100 |
| Dimensions (mm) |
Length |
62500 |
| Dimensions (mm) |
Width |
2370 |
| Dimensions (mm) |
Height |
2620 |
| Wheelbase (mm) |
Wheelbase (mm) |
3500/3800 |
| Track (front/rear) (mm) |
Track (front/rear) (mm) |
1880 /1800，1860 |
| Front overhang / Rear overhang (mm) |
Front overhang / Rear overhang (mm) |
1430/1320 |
| Approach angle / Departure angle (°) |
Approach angle / Departure angle (°) |
20/18 |
| Frame section dimensions (mm) |
Frame section dimensions (mm) |
232×75×6.5 |
| Minimum ground clearance (mm) |
Minimum ground clearance (mm) |
|
| Engine |
Manufacturer |
Dongfeng Motor Co., Ltd. Commercial Vehicle Company engine |
| Engine |
Model |
EQ160-30 |
| Engine |
Displacement / Rated power (ml/kW) |
4，75/118 |
| Engine |
Max torque/speed: |
550/1300-1800 |
| Clutch |
Clutch |
Φ395mm diaphragm |
| Transmission |
Transmission |
Dongfeng 6-speed DF6S650 gearbox |
| Front axle |
Front axle |
4.5-ton class steering front axle |
| Middle and rear axles |
Middle and rear axles |
8-ton Dongfeng single rear axle |
| Steering gear |
Steering gear |
Integral power steering gear |
| Tire specification |
Tire specification |
8.250-20 |
| Cab |
Cab |
Low roof cab-over 1.5-row single sleeper cab |
| Fuel tank (L) |
Fuel tank (L) |
160 |
